整合SSM

2023-05-27 SSM SpringMVC Comments

环境要求

环境：

IDEA
MySQL 5.7.19
Tomcat 9
Maven 3.6

要求：
需要熟练掌握MySQL数据库，Spring，JavaWeb及MyBatis知识，简单的前端知识；

最简单的项目：

步骤：

新建数据库，建表
新建Maven项目。添加web的支持
导入相关的pom依赖
Maven资源过滤设置
建立基本结构和配置框架「建立包，创建两个xml文件」
- com.kuang.pojo
- com.kuang.dao
- com.kuang.service
- com.kuang.controller
- mybatis-config.xml
- applicationContext.xml
Mybatis层编写
1. 数据库配置文件 database.properties
2. IDEA关联数据库
3. 编写MyBatis的核心配置文件
4. 编写数据库对应的实体类「使用lombok插件」
5. 编写Dao层的 Mapper接口
6. 编写接口对应的 Mapper.xml 文件。需要导入MyBatis的包
7. 编写Service层的接口和实现类
Spring层
1. 配置Spring整合MyBatis，我们这里数据源使用c3p0连接池
2. 编写Spring整合Mybatis的相关的配置文件； spring-dao.xml
3. Spring整合service层
SpringMVC层
1. web.xml
2. spring-mvc.xml
3. Spring配置整合文件，applicationContext.xml
4. Controller 和视图层编写
  1. BookController 类编写，方法一：查询全部书籍
  2. 编写首页 index.jsp
  3. 书籍列表页面 allbook.jsp
  4. BookController 类编写，方法二：添加书籍
  5. 添加书籍页面：addBook.jsp
  6. BookController 类编写，方法三：修改书籍
  7. 修改书籍页面 updateBook.jsp
  8. BookController 类编写，方法四：删除书
配置Tomcat，运行

数据库环境

创建一个存放书籍数据的数据库表

CREATE DATABASE `ssmbuild`;
USE `ssmbuild`;
DROP TABLE IF EXISTS `books`;
CREATE TABLE `books` (
  `bookID` INT(10) NOT NULL AUTO_INCREMENT COMMENT '书id',
  `bookName` VARCHAR(100) NOT NULL COMMENT '书名',
  `bookCounts` INT(11) NOT NULL COMMENT '数量',
  `detail` VARCHAR(200) NOT NULL COMMENT '描述',
  KEY `bookID` (`bookID`)
) ENGINE=INNODB DEFAULT CHARSET=utf8
INSERT  INTO `books`(`bookID`,`bookName`,`bookCounts`,`detail`)VALUES
(1,'Java',1,'从入门到放弃'),
(2,'MySQL',10,'从删库到跑路'),
(3,'Linux',5,'从进门到进牢');

基本环境搭建

新建Maven项目！ ssmbuild ，添加web的支持

导入相关的pom依赖！

<dependencies>
    <!--Junit-->
    <dependency>
        <groupId>junit</groupId>
        <artifactId>junit</artifactId>
        <version>4.12</version>
    </dependency>
    <!--数据库驱动-->
    <dependency>
        <groupId>mysql</groupId>
        <artifactId>mysql-connector-java</artifactId>
        <version>5.1.47</version>
    </dependency>
    <!-- 数据库连接池 -->
    <dependency>
        <groupId>com.mchange</groupId>
        <artifactId>c3p0</artifactId>
        <version>0.9.5.2</version>
    </dependency>
    <!--Servlet - JSP -->
    <dependency>
        <groupId>javax.servlet</groupId>
        <artifactId>servlet-api</artifactId>
        <version>2.5</version>
    </dependency>
    <dependency>
        <groupId>javax.servlet.jsp</groupId>
        <artifactId>jsp-api</artifactId>
        <version>2.2</version>
    </dependency>
    <dependency>
        <groupId>javax.servlet</groupId>
        <artifactId>jstl</artifactId>
        <version>1.2</version>
    </dependency>
    <!--Mybatis-->
    <dependency>
        <groupId>org.mybatis</groupId>
        <artifactId>mybatis</artifactId>
        <version>3.5.2</version>
    </dependency>
    <dependency>
        <groupId>org.mybatis</groupId>
        <artifactId>mybatis-spring</artifactId>
        <version>2.0.2</version>
    </dependency>
    <!--Spring-->
    <dependency>
        <groupId>org.springframework</groupId>
        <artifactId>spring-webmvc</artifactId>
        <version>5.1.9.RELEASE</version>
    </dependency>
    <dependency>
        <groupId>org.springframework</groupId>
        <artifactId>spring-jdbc</artifactId>
        <version>5.1.9.RELEASE</version>
    </dependency>
</dependencies>

在pom.xml，Maven资源过滤设置

<build>
    <resources>
        <resource>
            <directory>src/main/java</directory>
            <includes>
                <include>**/*.properties</include>
                <include>**/*.xml</include>
            </includes>
            <filtering>false</filtering>
        </resource>
        <resource>
            <directory>src/main/resources</directory>
            <includes>
                <include>**/*.properties</include>
                <include>**/*.xml</include>
            </includes>
            <filtering>false</filtering>
        </resource>
    </resources>
</build>

建立基本结构和配置框架！

com.kuang.pojo
com.kuang.dao
com.kuang.service
com.kuang.controller

mybatis-config.xml

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE configuration
        PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
        "<http://mybatis.org/dtd/mybatis-3-config.dtd>">
<configuration>
</configuration>

applicationContext.xml

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="<http://www.springframework.org/schema/beans>"
       xmlns:xsi="<http://www.w3.org/2001/XMLSchema-instance>"
       xsi:schemaLocation="<http://www.springframework.org/schema/beans>
        <http://www.springframework.org/schema/beans/spring-beans.xsd>">
</beans>

Mybatis层编写

数据库配置文件 database.properties

jdbc.driver=com.mysql.jdbc.Driver
jdbc.url=jdbc:mysql://localhost:3306/ssmbuild?useSSL=true&useUnicode=true&characterEncoding=utf8
jdbc.username=root
jdbc.password=123456

IDEA关联数据库

编写MyBatis的核心配置文件

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE configuration
        PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
        "<http://mybatis.org/dtd/mybatis-3-config.dtd>">
<configuration>
    <typeAliases>
        <package name="com.kuang.pojo"/>
    </typeAliases>
    <mappers>
        <mapper resource="com/kuang/dao/BookMapper.xml"/>
    </mappers>
</configuration>

编写数据库对应的实体类 com.kuang.pojo.Books

使用lombok插件！

package com.kuang.pojo;
import lombok.AllArgsConstructor;
import lombok.Data;
import lombok.NoArgsConstructor;
@Data
@AllArgsConstructor
@NoArgsConstructor
public class Books {
    private int bookID;
    private String bookName;
    private int bookCounts;
    private String detail;
}

编写Dao层的 Mapper接口！

package com.kuang.dao;
import com.kuang.pojo.Books;
import java.util.List;
public interface BookMapper {
    //增加一个Book
    int addBook(Books book);
    //根据id删除一个Book
    int deleteBookById(int id);
    //更新Book
    int updateBook(Books books);
    //根据id查询,返回一个Book
    Books queryBookById(int id);
    //查询全部Book,返回list集合
    List<Books> queryAllBook();
}

编写接口对应的 Mapper.xml 文件。需要导入MyBatis的包；

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE mapper
        PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
        "<http://mybatis.org/dtd/mybatis-3-mapper.dtd>">
<mapper namespace="com.kuang.dao.BookMapper">
    <!--增加一个Book-->
    <insert id="addBook" parameterType="Books">
        insert into ssmbuild.books(bookName,bookCounts,detail)
        values (#{bookName}, #{bookCounts}, #{detail})
    </insert>
    <!--根据id删除一个Book-->
    <delete id="deleteBookById" parameterType="int">
        delete from ssmbuild.books where bookID=#{bookID}
    </delete>
    <!--更新Book-->
    <update id="updateBook" parameterType="Books">
        update ssmbuild.books
        set bookName = #{bookName},bookCounts = #{bookCounts},detail = #{detail}
        where bookID = #{bookID}
    </update>
    <!--根据id查询,返回一个Book-->
    <select id="queryBookById" resultType="Books">
        select * from ssmbuild.books
        where bookID = #{bookID}
    </select>
    <!--查询全部Book-->
    <select id="queryAllBook" resultType="Books">
        SELECT * from ssmbuild.books
    </select>
</mapper>

编写Service层的接口和实现类

接口：

package com.kuang.service;
import com.kuang.pojo.Books;
import java.util.List;
//BookService:底下需要去实现,调用dao层
public interface BookService {
    //增加一个Book
    int addBook(Books book);
    //根据id删除一个Book
    int deleteBookById(int id);
    //更新Book
    int updateBook(Books books);
    //根据id查询,返回一个Book
    Books queryBookById(int id);
    //查询全部Book,返回list集合
    List<Books> queryAllBook();
}

实现类：

package com.kuang.service;
import com.kuang.dao.BookMapper;
import com.kuang.pojo.Books;
import java.util.List;
public class BookServiceImpl implements BookService {
    //调用dao层的操作，设置一个set接口，方便Spring管理
    private BookMapper bookMapper;
    public void setBookMapper(BookMapper bookMapper) {
        this.bookMapper = bookMapper;
    }
    public int addBook(Books book) {
        return bookMapper.addBook(book);
    }
    public int deleteBookById(int id) {
        return bookMapper.deleteBookById(id);
    }
    public int updateBook(Books books) {
        return bookMapper.updateBook(books);
    }
    public Books queryBookById(int id) {
        return bookMapper.queryBookById(id);
    }
    public List<Books> queryAllBook() {
        return bookMapper.queryAllBook();
    }
}

OK，到此，底层需求操作编写完毕！

Spring层

配置Spring整合MyBatis，我们这里数据源使用c3p0连接池；

我们去编写Spring整合Mybatis的相关的配置文件； spring-dao.xml

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="<http://www.springframework.org/schema/beans>"
       xmlns:xsi="<http://www.w3.org/2001/XMLSchema-instance>"
       xmlns:context="<http://www.springframework.org/schema/context>"
       xsi:schemaLocation="<http://www.springframework.org/schema/beans>
        <http://www.springframework.org/schema/beans/spring-beans.xsd>
        <http://www.springframework.org/schema/context>
        <https://www.springframework.org/schema/context/spring-context.xsd>">
    <!-- 配置整合mybatis -->
    <!-- 1.关联数据库文件 -->
    <context:property-placeholder location="classpath:database.properties"/>
    <!-- 2.数据库连接池 -->
    <!--数据库连接池
        dbcp  半自动化操作  不能自动连接
        c3p0  自动化操作（自动的加载配置文件 并且设置到对象里面）
    -->
    <bean id="dataSource" class="com.mchange.v2.c3p0.ComboPooledDataSource">
        <!-- 配置连接池属性 -->
        <property name="driverClass" value="${jdbc.driver}"/>
        <property name="jdbcUrl" value="${jdbc.url}"/>
        <property name="user" value="${jdbc.username}"/>
        <property name="password" value="${jdbc.password}"/>
        <!-- c3p0连接池的私有属性 -->
        <property name="maxPoolSize" value="30"/>
        <property name="minPoolSize" value="10"/>
        <!-- 关闭连接后不自动commit -->
        <property name="autoCommitOnClose" value="false"/>
        <!-- 获取连接超时时间 -->
        <property name="checkoutTimeout" value="10000"/>
        <!-- 当获取连接失败重试次数 -->
        <property name="acquireRetryAttempts" value="2"/>
    </bean>
    <!-- 3.配置SqlSessionFactory对象 -->
    <bean id="sqlSessionFactory" class="org.mybatis.spring.SqlSessionFactoryBean">
        <!-- 注入数据库连接池 -->
        <property name="dataSource" ref="dataSource"/>
        <!-- 配置MyBaties全局配置文件:mybatis-config.xml -->
        <property name="configLocation" value="classpath:mybatis-config.xml"/>
    </bean>
    <!-- 4.配置扫描Dao接口包，动态实现Dao接口注入到spring容器中 -->
    <!--解释 ： https://www.cnblogs.com/jpfss/p/7799806.html-->
    <bean class="org.mybatis.spring.mapper.MapperScannerConfigurer">
        <!-- 注入sqlSessionFactory -->
        <property name="sqlSessionFactoryBeanName" value="sqlSessionFactory"/>
        <!-- 给出需要扫描Dao接口包 -->
        <property name="basePackage" value="com.kuang.dao"/>
    </bean>
</beans>

Spring整合service层

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="<http://www.springframework.org/schema/beans>"
       xmlns:xsi="<http://www.w3.org/2001/XMLSchema-instance>"
       xmlns:context="<http://www.springframework.org/schema/context>"
       xsi:schemaLocation="<http://www.springframework.org/schema/beans>
    <http://www.springframework.org/schema/beans/spring-beans.xsd>
    <http://www.springframework.org/schema/context>
    <http://www.springframework.org/schema/context/spring-context.xsd>">
    <!-- 扫描service相关的bean -->
    <context:component-scan base-package="com.kuang.service" />
    <!--BookServiceImpl注入到IOC容器中-->
    <bean id="BookServiceImpl" class="com.kuang.service.BookServiceImpl">
        <property name="bookMapper" ref="bookMapper"/>
    </bean>
    <!-- 配置事务管理器 -->
    <bean id="transactionManager" class="org.springframework.jdbc.datasource.DataSourceTransactionManager">
        <!-- 注入数据库连接池 -->
        <property name="dataSource" ref="dataSource" />
    </bean>
</beans>

Spring层搞定！再次理解一下，Spring就是一个大杂烩，一个容器！对吧！

SpringMVC层

web.xml

<?xml version="1.0" encoding="UTF-8"?>
<web-app xmlns="<http://xmlns.jcp.org/xml/ns/javaee>"
         xmlns:xsi="<http://www.w3.org/2001/XMLSchema-instance>"
         xsi:schemaLocation="<http://xmlns.jcp.org/xml/ns/javaee> <http://xmlns.jcp.org/xml/ns/javaee/web-app_4_0.xsd>"
         version="4.0">
    <!--DispatcherServlet-->
    <servlet>
        <servlet-name>DispatcherServlet</servlet-name>
        <servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class>
        <init-param>
            <param-name>contextConfigLocation</param-name>
            <!--一定要注意:我们这里加载的是总的配置文件，之前被这里坑了！-->
            <param-value>classpath:applicationContext.xml</param-value>
        </init-param>
        <load-on-startup>1</load-on-startup>
    </servlet>
    <servlet-mapping>
        <servlet-name>DispatcherServlet</servlet-name>
        <url-pattern>/</url-pattern>
    </servlet-mapping>
    <!--encodingFilter-->
    <filter>
        <filter-name>encodingFilter</filter-name>
        <filter-class>
            org.springframework.web.filter.CharacterEncodingFilter
        </filter-class>
        <init-param>
            <param-name>encoding</param-name>
            <param-value>utf-8</param-value>
        </init-param>
    </filter>
    <filter-mapping>
        <filter-name>encodingFilter</filter-name>
        <url-pattern>/*</url-pattern>
    </filter-mapping>
    <!--Session过期时间-->
    <session-config>
        <session-timeout>15</session-timeout>
    </session-config>
</web-app>

spring-mvc.xml

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="<http://www.springframework.org/schema/beans>"
       xmlns:xsi="<http://www.w3.org/2001/XMLSchema-instance>"
       xmlns:context="<http://www.springframework.org/schema/context>"
       xmlns:mvc="<http://www.springframework.org/schema/mvc>"
       xsi:schemaLocation="<http://www.springframework.org/schema/beans>
    <http://www.springframework.org/schema/beans/spring-beans.xsd>
    <http://www.springframework.org/schema/context>
    <http://www.springframework.org/schema/context/spring-context.xsd>
    <http://www.springframework.org/schema/mvc>
    <https://www.springframework.org/schema/mvc/spring-mvc.xsd>">
    <!-- 配置SpringMVC -->
    <!-- 1.开启SpringMVC注解驱动 -->
    <mvc:annotation-driven />
    <!-- 2.静态资源默认servlet配置-->
    <mvc:default-servlet-handler/>
    <!-- 3.配置jsp 显示ViewResolver视图解析器 -->
    <bean class="org.springframework.web.servlet.view.InternalResourceViewResolver">
        <property name="viewClass" value="org.springframework.web.servlet.view.JstlView" />
        <property name="prefix" value="/WEB-INF/jsp/" />
        <property name="suffix" value=".jsp" />
    </bean>
    <!-- 4.扫描web相关的bean -->
    <context:component-scan base-package="com.kuang.controller" />
</beans>

Spring配置整合文件，applicationContext.xml

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="<http://www.springframework.org/schema/beans>"
       xmlns:xsi="<http://www.w3.org/2001/XMLSchema-instance>"
       xsi:schemaLocation="<http://www.springframework.org/schema/beans>
        <http://www.springframework.org/schema/beans/spring-beans.xsd>">
    <import resource="spring-dao.xml"/>
    <import resource="spring-service.xml"/>
    <import resource="spring-mvc.xml"/>
</beans>

配置文件，暂时结束！Controller 和视图层编写

BookController 类编写，方法一：查询全部书籍

@Controller
@RequestMapping("/book")
public class BookController {
    @Autowired
    @Qualifier("BookServiceImpl")
    private BookService bookService;
    @RequestMapping("/allBook")
    public String list(Model model) {
        List<Books> list = bookService.queryAllBook();
        model.addAttribute("list", list);
        return "allBook";
    }
}

编写首页 index.jsp

<%@ page language="java" contentType="text/html; charset=UTF-8" pageEncoding="UTF-8" %>
<!DOCTYPE HTML>
<html>
<head>
    <title>首页</title>
    <style type="text/css">
        a {
            text-decoration: none;
            color: black;
            font-size: 18px;
        }
        h3 {
            width: 180px;
            height: 38px;
            margin: 100px auto;
            text-align: center;
            line-height: 38px;
            background: deepskyblue;
            border-radius: 4px;
        }
    </style>
</head>
<body>
<h3>
    <a href="${pageContext.request.contextPath}/book/allBook">点击进入列表页</a>
</h3>
</body>
</html>

书籍列表页面 allbook.jsp

<%@ taglib prefix="c" uri="<http://java.sun.com/jsp/jstl/core>" %>
<%@ page contentType="text/html;charset=UTF-8" language="java" %>
<html>
<head>
    <title>书籍列表</title>
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <!-- 引入 Bootstrap -->
    <link href="<https://cdn.bootcss.com/bootstrap/3.3.7/css/bootstrap.min.css>" rel="stylesheet">
</head>
<body>
<div class="container">
    <div class="row clearfix">
        <div class="col-md-12 column">
            <div class="page-header">
                <h1>
                    <small>书籍列表 —— 显示所有书籍</small>
                </h1>
            </div>
        </div>
    </div>
    <div class="row">
        <div class="col-md-4 column">
            <a class="btn btn-primary" href="${pageContext.request.contextPath}/book/toAddBook">新增</a>
        </div>
    </div>
    <div class="row clearfix">
        <div class="col-md-12 column">
            <table class="table table-hover table-striped">
                <thead>
                <tr>
                    <th>书籍编号</th>
                    <th>书籍名字</th>
                    <th>书籍数量</th>
                    <th>书籍详情</th>
                    <th>操作</th>
                </tr>
                </thead>
                <tbody>
                <c:forEach var="book" items="${requestScope.get('list')}">
                    <tr>
                        <td>${book.getBookID()}</td>
                        <td>${book.getBookName()}</td>
                        <td>${book.getBookCounts()}</td>
                        <td>${book.getDetail()}</td>
                        <td>
                            <a href="${pageContext.request.contextPath}/book/toUpdateBook?id=${book.getBookID()}">更改</a> |
                            <a href="${pageContext.request.contextPath}/book/del/${book.getBookID()}">删除</a>
                        </td>
                    </tr>
                </c:forEach>
                </tbody>
            </table>
        </div>
    </div>
</div>

BookController 类编写，方法二：添加书籍

@RequestMapping("/toAddBook")
public String toAddPaper() {
    return "addBook";
}
@RequestMapping("/addBook")
public String addPaper(Books books) {
    System.out.println(books);
    bookService.addBook(books);
    return "redirect:/book/allBook";
}

添加书籍页面：addBook.jsp

<%@ taglib prefix="c" uri="<http://java.sun.com/jsp/jstl/core>" %>
<%@ page contentType="text/html;charset=UTF-8" language="java" %>
<html>
<head>
    <title>新增书籍</title>
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <!-- 引入 Bootstrap -->
    <link href="<https://cdn.bootcss.com/bootstrap/3.3.7/css/bootstrap.min.css>" rel="stylesheet">
</head>
<body>
<div class="container">
    <div class="row clearfix">
        <div class="col-md-12 column">
            <div class="page-header">
                <h1>
                    <small>新增书籍</small>
                </h1>
            </div>
        </div>
    </div>
    <form action="${pageContext.request.contextPath}/book/addBook" method="post">
        书籍名称：<input type="text" name="bookName"><br><br><br>
        书籍数量：<input type="text" name="bookCounts"><br><br><br>
        书籍详情：<input type="text" name="detail"><br><br><br>
        <input type="submit" value="添加">
    </form>
</div>

BookController 类编写，方法三：修改书籍

@RequestMapping("/toUpdateBook")
public String toUpdateBook(Model model, int id) {
    Books books = bookService.queryBookById(id);
    System.out.println(books);
    model.addAttribute("book",books );
    return "updateBook";
}
@RequestMapping("/updateBook")
public String updateBook(Model model, Books book) {
    System.out.println(book);
    bookService.updateBook(book);
    Books books = bookService.queryBookById(book.getBookID());
    model.addAttribute("books", books);
    return "redirect:/book/allBook";
}

修改书籍页面 updateBook.jsp

<%@ taglib prefix="c" uri="<http://java.sun.com/jsp/jstl/core>" %>
<%@ page contentType="text/html;charset=UTF-8" language="java" %>
<html>
<head>
    <title>修改信息</title>
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <!-- 引入 Bootstrap -->
    <link href="<https://cdn.bootcss.com/bootstrap/3.3.7/css/bootstrap.min.css>" rel="stylesheet">
</head>
<body>
<div class="container">
    <div class="row clearfix">
        <div class="col-md-12 column">
            <div class="page-header">
                <h1>
                    <small>修改信息</small>
                </h1>
            </div>
        </div>
    </div>
    <form action="${pageContext.request.contextPath}/book/updateBook" method="post">
        <input type="hidden" name="bookID" value="${book.getBookID()}"/>
        书籍名称：<input type="text" name="bookName" value="${book.getBookName()}"/>
        书籍数量：<input type="text" name="bookCounts" value="${book.getBookCounts()}"/>
        书籍详情：<input type="text" name="detail" value="${book.getDetail() }"/>
        <input type="submit" value="提交"/>
    </form>
</div>

BookController 类编写，方法四：删除书籍

@RequestMapping("/del/{bookId}")
public String deleteBook(@PathVariable("bookId") int id) {
    bookService.deleteBookById(id);
    return "redirect:/book/allBook";
}

配置Tomcat，进行运行！

到目前为止，这个SSM项目整合已经完全的OK了，可以直接运行进行测试！这个练习十分的重要，大家需要保证，不看任何东西，自己也可以完整的实现出来！

项目结构图

小结及展望

SSM框架的重要程度是不言而喻的，学到这里，大家已经可以进行基本网站的单独开发。但是这只是增删改查的基本操作。

我们后面还要学习一些 SpringMVC 的知识！

Ajax 和 Json
文件上传和下载
拦截器

SpringBoot、SpringCloud开发！

本文链接： https://anleyang.site/2023/05/27/ssmNotes/整合SSM/

版权声明： 本博客所有文章除特别声明外，均采用 CC BY 4.0 CN协议许可协议。转载请注明出处！

Yang YangJava Development Engineer

Keep looking, don't settle.
